Small Packaged Units

Small Packaged Units (Water-to-Air) Heat Pumps .5-6 tons

Tranquility® 30 Two-Stage (TE) Series

Tranquility® 22 Digital Two-Stage (TZ) Series

Tranquility® 22 Digital Compact Two-Stage (TY) Series

Tranquility® 20 Single-Stage (TS) Series

Tranquility® 16 Single-Stage (TR) Series

Tranquility® 16 Compact Single-Stage (TC) Series

The Tranquility® 30 Digital Series delivers the ultimate in efficiency, comfort, reliability and serviceability – intelligently driven by the iGate®, the industry’s first two-way communicating control, two-stage compressor, variable speed fan and industry-first vFlow® internal variable water flow components. The Tranquility 30 also delivers reliable operation, lower operating cost and compact installation.Available with multiple cabinet options (vertical upflow, vertical downflow and horizontal) the Tranquility 30 Digital offers a unit for most any installation. With an extended range refrigerant circuit, capable of ground loop (geothermal) applications as well as water loop (boiler-tower) applications, the Tranquility 30 Digital is among the most flexible in the industry. Standard features such as Copeland UltraTech™ two-stage scroll compressor, ECM variable fan motor, digital communicating controls, powder coated galvanized steel cabinet, stainless steel drain pan and foil-backed air handler insulation are just some of the features of the innovative Tranquility 30 Digital Series.The Tranquility 30 Digital Series also offers advanced options that allow for energy efficient, application flexibility. Available options include hot water generator, enhanced iGate digital communicating controls, coated air coils, extended range insulation, UltraQuiet package, vFlow internal variable water flow, and internal secondary circulator.

Sizes 026 (2 ton, 7.0 kW) through 072 (6 tons, 19.3 kW)
Advanced Controls – iGate communicating control provides advanced unit functionality and comprehensive configuration, monitoring and diagnostic capabilities through digital communication links with the variable-speed fan motor, variable-speed source pump (or modulating valve) and communicating thermostat or configuration/diagnostic tool.
Internal Variable Water Flow – Industry-first, built-in vFlow replaces a traditionally inefficient, external component of the geothermal system (water circulation) with an ultra-high efficient, variable speed, internal water flow system consisting of an internal variable speed circulator or an internal modulating motorized water valve.
EarthPure® (HFC-410A) refrigerant
Copeland UltraTech™ two-stage scroll compressors
ECM variable speed communicating fan motor with soft start
Exceeds ASHRAE 90.1 efficiencies
Part load operation significantly lowers annual operating costs
Galvanized steel construction with black mat polyester powder coat paint and silver accents
Stainless steel drain pan
Unique double isolation compressor mounting for quiet operation
TXV metering device
Extended range (20 to 120°F, -6.7 to 48.9°C) operation
Eight safeties standard
ClimaDry® II Modulating Reheat Option

Downloads (Literature)

Easy access control box contains DXM2 (iGate) communicating control, a robust microprocessor based controller that is advanced and feature-laden for maximum application flexibility. (Optional DDC Controllers also available)
Industry-first, built-in vFlow® replaces traditionally inefficient, external pumping components with an ultra-high efficient, variable speed, internal water flow system to intelligently vary the water ﬂow to minimize pump energy consumption and improve system reliability.
Easy to remove blower housing for quick service and ECM variable speed motor. Foil faced insulation in the blower section and fiberglass insulation in the compressor section.
Copeland UltraTech™ two-stage compressor with dual compressor vibration isolation. Easy service access from multiple sides.

TE Series

1) DXM2

2) vflow

3) Motor

4) Compressor

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TE 026-072
208-230/60/1	DXM2	ECM	None	With MOD Valve	96B0242N01
				With ISP	96B0242N05
				With Climadry®	96B0242N08
				With Variable Pump	96B0242N12
			LON	With MOD Valve	96B0242N02
				With ISP	96B0242N06
				With Climadry®	96B0242N20
				With Variable Pump	96B0242N56
			MPC	With MOD Valve	96B0242N03
				With ISP	96B0242N07
				With Climadry®	96B0242N21
				With Variable Pump	96B0242N55

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TE 026-072
265/60/1	DXM2	ECM	None	With MOD Valve	96B0242N01
				With ISP	96B0242N05
				With Climadry®	96B0242N08
				With Variable Pump	96B0242N09
			LON	With MOD Valve	96B0242N02
				With ISP	96B0242N06
				With Climadry®	96B0242N20
				With Variable Pump	96B0242N57
			MPC	With MOD Valve	96B0242N03
				With ISP	96B0242N07
				With Climadry®	96B0242N21
				With Variable Pump	96B0242N58

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TE 026-072
208-230/60/3	DXM2	ECM	None	With MOD Valve	96B0243N01
				With ISP	96B0243N05
				With Climadry®	96B0243N08
				With Variable Pump	96B0243N09
			LON	With MOD Valve	96B0243N02
				With ISP	96B0243N06
				With Climadry®	96B0243N12
				With Variable Pump	96B0242N61
			MPC	With MOD Valve	96B0243N03
				With ISP	96B0243N07
				With Climadry®	96B0243N11
				With Variable Pump	96B0242N62

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TE 026-072
460/60/3	DXM2	ECM	None	With MOD Valve	96B0244N01
				With ISP	96B0244N05
				With Climadry®	96B0244N08
				With Variable Pump	96B0244N09
			LON	With MOD Valve	96B0244N02
				With ISP	96B0244N06
				With Climadry®	96B0244N11
				With Variable Pump	96B0242N59
			MPC	With MOD Valve	96B0244N03
				With ISP	96B0244N07
				With Climadry®	96B0244N10
				With Variable Pump	96B0242N60

The Tranquility® High-Efficiency (TZ) Series offers high efficient 2-stage operation in a simple cabinet design.

The Tranquility High-Efficiency Series also offers options that allow for application flexibility. Available options include hot water generator, enhanced iGate® controls, coated air coils, extended range insulation, UltraQuiet package, vFlow® internal variable water flow, motorized water valve, and automatic water flow valves.

Sizes 024 (2 ton, 7.0 kW) through 060 (5 tons, 17.6 kW)
Copeland UltraTech 2-stage scroll compressor
Exceeds ASHRAE 90.1 efficiencies
Galvanized steel construction
Galvanized steel drain pan with powder coat finish
Sound absorbing glass fiber insulation
Unique double isolation compressor mounting for quiet operation
Insulated divider & separate compressor/air handler compartments
Field convertible discharge air arrangement for horizontal units
Variable speed ECM fan motor
Internally trapped condensate drain line (vertical units only)
Eight safeties standard
Extended range (20 – 120°F, -6.7 – 48.9°C) capable
Advanced Controls — iGate communicating control provides advanced unit functionality & comprehensive configuration, monitoring & diagnostic capabilities through digital communication links with the variable-speed fan motor, variable-speed source pump (or modulating valve) & communicating thermostat or Configuration/Diagnostic tool.
Internal Variable Water Flow — Industry-first, Built-in vFlow replaces a traditionally inefficient, external component of the geothermal system (water circulation) with an ultra-high-efficient, variable speed, internal water flow system.

Downloads (Literature)

Easy to remove blower housing for quick service and variable speed ECM fan motor. Easy service access from multiple sides.
Dual compressor vibration isolation for quiet operation.
Easy access control box contains advanced digital controls with Remote Service Sentinel. Optional DDC controllers are available. iGateTM Advanced Control.
Galvanized steel insulated drain pan with condensate overflow protection.

TZ Series

1) DXM2

2) vFlow

3) Motor

4) Compressor

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TZ 024-060
208-230/60/1	DXM2	ECM	None	None	96B0231N11
				Mod Valve	96B0242N40
				ISP	96B0242N45
			LON	None	96B0231N12
				Mod Valve	96B0242N41
				ISP	96B0242N46
			MPC	None	96B0231N13
				Mod Valve	96B0242N42
				ISP	96B0242N47

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TZ 024-060
265/60/1	DXM2	ECM	None	None	96B0231N11
				Mod Valve	96B0242N40
				ISP	96B0242N45
			LON	None	96B0231N12
				Mod Valve	96B0242N41
				ISP	96B0242N46
			MPC	None	96B0231N13
				Mod Valve	96B0242N42
				ISP	96B0242N47

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TZ 024-060
208-230/60/3	DXM2	ECM	None	None	96B0232N21
				Mod Valve	96B0243N40
				ISP	96B0243N45
			LON	None	96B0232N22
				Mod Valve	96B0243N41
				ISP	96B0243N46
			MPC	None	96B0232N23
				Mod Valve	96B0243N42
				ISP	96B0243N47

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TZ 024-060
460/60/3	DXM2	ECM	None	None	96B0232N31
				Mod Valve	96B0244N40
				ISP	96B0244N45
			LON	None	96B0232N32
				Mod Valve	96B0244N41
				ISP	96B0244N46
			MPC	None	96B0232N33
				Mod Valve	96B0244N42
				ISP	96B0244N47

The Tranquility® 22 Compact (TY) Series raises the bar for water-source heat pump efficiencies, features and application flexibility. Not only does the Tranquility 22 Compact Series exceed ASHRAE 90.1 efficiencies with 2-stage operation. It also uses EarthPure® (HFC-410A) zero ozone depletion refrigerant, making it an extremely environmentally-friendly option.

With one of the smallest cabinets in the industry, the Tranquility 22 Compact (TY) Series will easily fit into tight spaces. Designed to be backward compatible with thousands of older water-source heat pumps, the Tranquility 22 Compact (TY) Series heat pump is packed full of the innovation you have come to expect from the experts at ClimateMaster such as the iGate® advanced control making the TY Series easy to operate and install.

Sizes 024 (2 ton, 7.0 kW) – 060 (5 tons, 17.6 kW)
Copeland Ultra-Tech 2-stage scroll compressor
EarthPure® (HFC-410A) refrigerant
Exceeds ASHRAE 90.1 efficiencies
Galvanized steel construction
Galvanized steel drain pan with powder coat finish
Sound absorbing glass fiber insulation
Unique double isolation compressor mounting for quiet operation
Insulated divider & separate compressor/air handler compartments
TXV metering device
Field convertible discharge air arrangement for horizontal units
Variable speed ECM fan motor
Internally trapped condensate drain line (vertical units)
Advanced Controls — iGate communicating control provides advanced unit functionality & comprehensive configuration, monitoring & diagnostic capabilities through digital communication links with the variable-speed fan motor, & communicating thermostat or Configuration/Diagnostic tool

Downloads (Literature)

Easy to remove blower housing for quick service & variable-speed ECM motor. Easy service access from multiple sides.
Dual compressor vibration isolation for quiet operation.
Easy access control box contains advanced digital controls with Remote Service Sentinel. Optional DDC controllers are available. iGate® advanced control.
Powder-coated insulated drain pan with condensate overflow protection.

1) Motor

2) Compressor

3) Control Board

4) Condensate & Sensor

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Wiring Diagrams TY 024-060
208-230/60/1	DXM2	ECM	None	96B0231N11
LON	96B0231N12
MPC	96B0231N13

Electrical

V-Hz-Ph

Control

Fan Motor

DDC

Wiring Diagrams

TY 024-060

208-230/60/1

DXM2

ECM

None

96B0231N11

LON

96B0231N12

MPC

96B0231N13

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Wiring Diagrams TY 024-060
265/60/1	DXM2	ECM	None	96B0231N11
LON	96B0231N12
MPC	96B0231N13

Electrical

V-Hz-Ph

Control

Fan Motor

DDC

Wiring Diagrams

TY 024-060

265/60/1

DXM2

ECM

None

96B0231N11

LON

96B0231N12

MPC

96B0231N13

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Wiring Diagrams TY 024-060
208-230/60/3	DXM2	ECM	None	96B0232N21
LON	96B0232N22
MPC	96B0232N23

Electrical

V-Hz-Ph

Control

Fan Motor

DDC

Wiring Diagrams

TY 024-060

208-230/60/3

DXM2

ECM

None

96B0232N21

LON

96B0232N22

MPC

96B0232N23

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Wiring Diagrams TY 024-060
460/60/3	DXM2	ECM	None	96B0232N31
LON	96B0232N32
MPC	96B0232N33

Electrical

V-Hz-Ph

Control

Fan Motor

DDC

Wiring Diagrams

TY 024-060

460/60/3

DXM2

ECM

None

96B0232N31

LON

96B0232N32

MPC

96B0232N33

The Tranquility 20 Single-Stage (TS) Series builds on ClimateMaster’s commitment to utilizing the most advanced technology and design to create one of the most efficient single-stage water-source heat pump available today. The Tranquility 20 Single-Stage Series combines EarthPure® (HFC-410A) refrigerant with the Scroll compressor (rotary in 012 and smaller) and either an ECM variable speed or PSC multi-speed fan motor to create unmatched performance and flexibility.

Sizes 006 (½ ton, 1.8 kW) – 070 (6 ton, 21.1 kW2)
Environmentally-friendly EarthPure® (HFC-410A) refrigerant
Unsurpassed efficiencies (far exceeds ASHRAE 90.1)
Copeland Scroll compressor (size 018 & above)
Multi-speed PSC fan motor (optional variable speed ECM motor on size 018 & above
Galvanized steel construction & powder coat paint on all units
Unique double isolation compressor mounting for quiet operation
Discharge muffler standard (except rotary compressors) for superior sound attenuation
Microprocessor controls standard (optional DXM and/or DDC controls)
Field convertible discharge air arrangement for horizontal units
Bi-directional, balanced port expansion valve refrigerant metering device standard
Standard range or extended range operation
Water connections securely mounted flush to the cabinet corner post (no backup wrench required)
8 safeties standard
ClimaDry® II Modulating Reheat Option

Downloads (Literature)

Easy access control box contains advanced digital controls with Remote Service Sentinel. Optional enhanced controls (DXM) & DDC controllers.
Standard stainless steel insulated drain pan with condensate overflow protection.
Easy to remove blower housing for quick service & optional variable-speed ECMmotor. Foil faced insulation in the blower section & fiberglass insulation in the compressor section.
Dual compressor vibration isolation for quiet operation. Easy service from multiple sides.

TS Series

1) Control Board

2) Condensate & Sensor

3) Motor

4) Compressor

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TS 006-070
208-230/60/1	CXM	PSC	None	None	96B0308N01
			LON	None	96B0308N02
			MPC	None	96B0308N03
		ECM	None	None	96B0308N06
			LON	None	96B0308N07
			MPC	None	96B0308N08

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TS 006-070
208-230/60/1	DXM2	PSC	None	None	96B0309N01
			None	w/Climadry®	96B0309N11
			LON	None	96B0309N02
			LON	w/Climadry®	96B0309N12
			MPC	None	96B0309N03
			MPC	w/Climadry®	96B0309N13
		ECM	None	None	96B0309N06
			None	w/Climadry®	96B0309N15
			LON	None	96B0309N07
			LON	w/Climadry®	96B0309N16
			MPC	None	96B0309N08
			MPC	w/Climadry®	96B0309N17

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TS 006-070
265/60/1	CXM	PSC	None	None	96B0308N01
			LON	None	96B0308N02
			MPC	None	96B0308N03
		ECM	None	None	96B0308N06
			LON	None	96B0308N07
			MPC	None	96B0308N08

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TS 006-070
265/60/1	DXM2	PSC	None	None	96B0309N01
			None	w/Climadry®	96B0309N11
			LON	None	96B0309N02
			LON	w/Climadry®	96B0309N12
			MPC	None	96B0309N03
			MPC	w/Climadry®	96B0309N13
		ECM	None	None	96B0309N06
			None	w/Climadry®	96B0309N15
			LON	None	96B0309N07
			LON	w/Climadry®	96B0309N16
			MPC	None	96B0309N08
			MPC	w/Climadry®	96B0309N17

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TS 006-070
208-230/60/3	CXM	PSC	None	None	96B0310N01
			LOM	None	96B0310N02
			MPC	None	96B0310N03
		ECM	None	None	96B0310N06
			LON	None	96B0310N07
			MPC	None	96B0310N08

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TS 006-070
208-230/60/3	DXM2	PSC	None	None	96B0311N01
			None	w/Climadry®	96B0311N11
			LON	None	96B0311N02
			LON	w/Climadry®	96B0311N12
			MPC	None	96B0311N03
			MPC	w/Climadry®	96B0311N13
		ECM	None	None	96B0311N06
			None	w/Climadry®	96B0311N15
			LON	None	96B0311N07
			LON	w/Climadry®	96B0311N16
			MPC	None	96B0311N08
			MPC	w/Climadry®	96B0311N17

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TS 006-070
460/60/3	CXM	PSC	None	None	96B0312N01
			LON	None	96B0312N02
			MPC	None	96B0312N03
		ECM	None	None	96B0312N06
			LON	None	96B0312N07
			MPC	None	96B0312N08

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagrams TS 006-070
460/60/3	DXM2	PSC	None	None	96B0313N01
			None	w/Climadry®	96B0313N11
			LON	None	96B0313N02
			LON	w/Climadry®	96B0313N12
			MPC	None	96B0313N03
			MPC	w/Climadry®	96B0313N13
		ECM	None	None	96B0313N06
			None	w/Climadry®	96B0313N15
			LON	None	96B0313N07
			LON	w/Climadry®	96B0313N16
			MPC	None	96B0313N08
			MPC	w/Climadry®	96B0313N17

The Tranquility High-Efficiency (TR) Series offers high efficiency performance in a simple cabinet design.The Tranquility High-Efficiency Series also offers options that allow for application flexibility. Available options include ClimaDry™ dehumidification, hot water generator, enhanced controls, coated air coils, extended range insulation, UltraQuiet package, secondary circulating pump, motorized water valve, automatic water flow valves, CT & CVECM blowers and high static blowers.

Sizes 006 (1/2 ton, 1.8 kW) – 060 (5 tons, 17.6 kW)
Exceeds ASHRAE 90.1 efficiencies
Galvanized steel construction
Epoxy powder painted galvanized steel drain pan
Sound absorbing glass fiber insulation
Unique double isolation compressor mounting for quiet operation
Insulated divider and separate compressor/air handler compartments
Copeland scroll compressors (Size 024 and above)
Microprocessor controls standard (optional DDC controls)
Optional DXM2 control simplifies installation and commissioning
Field convertible discharge air arrangement for horizontal units
PSC 3-speed fan motor
Optional CT ECM or CV ECM available on all sizes
Internally trapped condensate drain line (vertical units only)
Eight safeties standard
Extended range (20 – 120°F, -6.7 – 48.9°C) capable

Downloads (Literature)

Dual compressor vibration isolation for quiet operation.
Easy to remove blower housing for quick service & PSC 3-speed motor. Easy service access from multiple sides.
Easy access control box contains advanced digital controls with Remote Service Sentinel. Optional enhanced controls (DXM2) & DDC controllers.
Epoxy powder-coated drain pan with condensate overflow protection.

TR Series

1) Compressor

2) Blower

3) Control Board

4) Condensate & Sensor

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TR 006-012	Wiring Diagram TR 015-060
208-230/60/1	CXM	PSC	None	None	96B0500N01	96B0500N11
			LON	None	96B0500N02	96B0500N12
			MPC	None	96B0500N03	96B0500N13
		ECM-CT	None	None	96B0506N01	96B0506N11
			None	Hybrid	96B0511N01	96B0511N11
			LON	None	96B0506N02	96B0506N12
			MPC	None	96B0506N03	96B0506N13
			MPC	Hybrid	96B0511N03	96B0511N13

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TR 006-012	Wiring Diagram TR 015-060	Wiring Diagram TR 024-060
208-230/60/1	DXM2	PSC	None	None	96B0521N01	96B0521N11	N/A
			None	w/Climadry®	N/A	N/A	96B0524N11
			LON	None	96B0521N02	96B0521N12	N/A
			LON	w/Climadry®	N/A	N/A	96B0524N12
			MPC	None	96B0521N03	96B0521N13	N/A
			MPC	w/Climadry®	N/A	N/A	96B0524N13
		ECM-CV	None	None	96B0523N01	96B0523N11	N/A
				Hybrid	96B0530N01	96B0530N11	N/A
				w/Climadry®	N/A	N/A	96B0525N11
			LON	None	96B0523N02	96B0523N12	N/A
			LON	w/Climadry®	N/A	N/A	96B0525N12
			MPC	None	96B0523N03	96B0523N13	N/A
				Hybrid	96B0530N03	96B0530N13	N/A
				w/Climadry®	N/A	N/A	96B0525N13
		ECT-CT	None	None	96B0527N01	96B0527N11	N/A
				Hybrid	96B0532N01	96B0532N11	N/A
				w/Climadry®	N/A	N/A	96B0528N11
			LON	None	96B0527N02	96B0527N12	N/A
			LON	w/Climadry®	N/A	N/A	96B0528N12
			MPC	None	96B0527N03	96B0527N13	N/A
				Hybrid	96B0532N03	96B0532N13	N/A
				w/Climadry®	N/A	N/A	96B0528N13

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TR 006-012	Wiring Diagram TR 015-060
265/60/1	CXM	PSC	None	None	96B0500N01	96B0500N11
			LON	None	96B0500N02	96B0500N12
			MPC	None	96B0500N03	96B0500N13
		ECM-CT	None	None	96B0506N01	96B0506N11
			None	Hybrid	96B0511N01	96B0511N11
			LON	None	96B0506N02	96B0506N12
			MPC	None	96B0506N03	96B0506N13
			MPC	Hybrid	96B0511N03	96B0511N13

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TR 006-012	Wiring Diagram TR 015-060	Wiring Diagram TR 024-060
265/60/1	DXM2	PSC	None	None	96B0521N01	96B0521N11	N/A
			None	w/Climadry®	N/A	N/A	96B0524N11
			LON	None	96B0521N02	96B0521N12	N/A
			LON	w/Climadry®	N/A	N/A	96B0524N12
			MPC	None	96B0521N03	96B0521N13	N/A
			MPC	w/Climadry®	N/A	N/A	96B0524N13
		ECM-CV	None	None	96B0523N01	96B0523N11	N/A
				Hybrid	96B0530N01	96B0530N11	N/A
				w/Climadry®	N/A	N/A	96B0525N11
			LON	None	96B0523N02	96B0523N12	N/A
			LON	w/Climadry®	N/A	N/A	96B0525N12
			MPC	None	96B0523N03	96B0523N13	N/A
				Hybrid	96B0530N03	96B0530N13	N/A
				w/Climadry®	N/A	N/A	96B0525N13
		ECT-CT	None	None	96B0527N01	96B0527N11	N/A
				Hybrid	96B0532N01	96B0532N11	N/A
				w/Climadry®	N/A	N/A	96B0528N11
			LON	None	96B0527N02	96B0527N12	N/A
			LON	w/Climadry®	N/A	N/A	96B0528N12
			MPC	None	96B0527N03	96B0527N13	N/A
				Hybrid	96B0532N03	96B0532N13	N/A
				w/Climadry®	N/A	N/A	96B0528N13

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TR 006-018	Wiring Diagram TR 024-060
208-230/60/3	CXM	PSC	None	None	N/A	96B0500N21
			LON	None	N/A	96B0500N22
			MPC	None	N/A	96B0500N23
		ECM-CT	None	None	N/A	96B0506N21
			None	Hybrid	N/A	96B0511N21
			LON	None	N/A	96B0506N22
			MPC	None	N/A	96B0506N23
			MPC	Hybrid	N/A	96B0511N23

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TR 006-018	Wiring Diagram TR 024-060
208-230/60/3	DXM2	PSC	None	None	N/A	96B0521N21
				Hybrid	N/A	96B0530N21
				w/Climadry®	N/A	96B0524N21
			LON	None	N/A	96B0521N22
			LON	w/Climadry®	N/A	96B0524N22
			MPC	None	N/A	96B0521N23
			MPC	w/Climadry®	N/A	96B0524N23
		ECM-CV	None	None	N/A	96B0523N21
			None	w/Climadry®	N/A	96B0525N21
			LON	None	N/A	96B0523N22
			LON	w/Climadry®	N/A	96B0525N22
			MPC	None	N/A	96B0523N23
				Hybrid	N/A	96B0530N23
				w/Climadry®	N/A	96B0525N23
		ECM-CT	None	None	N/A	96B0527N21
				Hybrid	N/A	96B0532N21
				w/Climadry®	N/A	96B0528N21
			LON	None	N/A	96B0527N22
			LON	w/Climadry®	N/A	96B0528N22
			MPC	None	N/A	96B0527N23
				Hybrid	N/A	96B0532N23
				w/Climadry®	N/A	96B0528N23

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TR 006-018	Wiring Diagram TR 024-060
460/60/3	CXM	PSC	None	None	N/A	96B0500N31
			LON	None	N/A	96B0500N32
			MPC	None	N/A	96B0500N33
		ECM-CT	None	None	N/A	96B0506N31
			None	Hybrid	N/A	96B0511N31
			LON	None	N/A	96B0506N32
			MPC	None	N/A	96B0506N33
			MPC	Hybrid	N/A	96B0511N33

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TR 006-018	Wiring Diagram TR 024-060
460/60/3	DXM2	PSC	None	None	N/A	96B0521N31
			None	w/Climadry®	N/A	96B0524N31
			LON	None	N/A	96B0521N32
			LON	w/Climadry®	N/A	96B0524N32
			MPC	None	N/A	96B0521N33
			MPC	w/Climadry®	N/A	96B0524N33
		ECM-CV	None	None	N/A	96B0523N31
				Hybrid	N/A	96B0530N31
				w/Climadry®	N/A	96B0525N31
			LON	None	N/A	96B0523N32
			LON	w/Climadry®	N/A	96B0525N32
			MPC	None	N/A	96B0523N33
				Hybrid	N/A	96B0530N33
				w/Climadry®	N/A	96B0525N33
		ECM-CT	None	None	N/A	96B0527N31
				Hybrid	N/A	96B0532N31
				w/Climadry®	N/A	96B0528N31
			LON	None	N/A	96B0527N32
			LON	w/Climadry®	N/A	96B0528N32
			MPC	None	N/A	96B0527N33
				Hybrid	N/A	96B0532N33
				w/Climadry®	N/A	96B0528N33

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TR 006-018	Wiring Diagram TR 024-060
575/60/3	CXM	PSC	None	None	N/A	96B0500N31
LON	None	N/A	96B0500N32
MPC	None	N/A	96B0500N33

Electrical

V-Hz-Ph

Control

Fan Motor

DDC

Options

Wiring Diagram

TR 006-018

Wiring Diagram

TR 024-060

575/60/3

CXM

PSC

None

N/A

96B0500N31

LON

None

N/A

96B0500N32

MPC

None

N/A

96B0500N33

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TR 006-018	Wiring Diagram TR 024-060
575/60/3	DXM2	PSC	None	None	N/A	96B0521N31
LON	None	N/A	96B0521N32
MPC	None	N/A	96B0521N33

Electrical

V-Hz-Ph

Control

Fan Motor

DDC

Options

Wiring Diagram

TR 006-018

Wiring Diagram

TR 024-060

575/60/3

DXM2

PSC

None

N/A

96B0521N31

LON

None

N/A

96B0521N32

MPC

None

N/A

96B0521N33

The Tranquility 16 Compact (TC) Series raises the bar for water-source heat pump efficiencies, features and application flexibility. Not only does the Tranquility 16 Compact Series exceed ASHRAE 90.1 efficiencies, but it also uses EarthPure® (HFC-410A) zero ozone depletion refrigerant, making it an extremely environmentally-friendly option. With one of the smallest cabinets in the industry, the Tranquility 16 Compact (TC) Series will easily fit into tight spaces. Designed to be backward compatible with thousands of older water-source heat pumps, the Tranquility 16 Compact (TC) Series heat pump is packed full of the innovation you have come to expect from the experts at ClimateMaster.

Sizes 006 (1/2 ton, 1.8 kW) through 060 (5 tons, 17.6 kW)
EarthPure® (HFC-410A) refrigerant
Exceeds ASHRAE 90.1 efficiencies
Galvanized steel construction
Epoxy powder painted galvanized steel drain pan (optional stainless steel drain pan)
Sound absorbing glass fiber insulation
Unique double isolation compressor mounting for quiet operation
Insulated divider & separate compressor/air handler compartments
Copeland scroll compressors (size 024 & above)
TXV metering device
Microprocessor controls standard (optional DDC controls)
Optional DXM2 control simplifies installation and commissioning
Field convertible discharge air arrangement for horizontal units
Optional water side economizer
Optional CT ECM or CV ECM available on all sizes

Downloads (Literature)

Dual compressor vibration isolation for quiet operation.
Easy to remove blower housing for quick service of 3-speed PSC, 5-speed CT ECM or variable speed CV ECM fan motor. Easy service from multiple sides.
Easy access control box contains advanced digital controls with Remote Service Sentinel. Optional enhanced controls (DXM2) & DDC controllers.
Epoxy powder painted drain pan with condensate overflow protection.
Optional water side economizer to maximize energy efficiency and meet code requirements

TC Series

1) Compressor

2) Blower

3) Control Board

4) Condensate & Sensor

5) Water Side Economizer

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TC 006-012	Wiring Diagram TC 015-060
208-230/60/1	CXM	PSC	None	None	96B0450N10	96B0450N15
			None	w/WSE	96B0452N10	96B0452N15
			LON	None	96B0450N11	96B0450N16
			MPC	None	96B0450N12	96B0450N17
		ECM-CT	None	None	96B0454N01	96B0454N11
			LON	None	96B0454N02	96B0454N12
			MPC	None	96B0454N03	96B0454N13

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TC 006-012	Wiring Diagram TC 015-060
208-230/60/1	DXM2	PSC	None	None	96B0466N01	96B0466N11
			None	w/WSE	96B0476N01	96B0476N11
			LON	None	96B0466N02	96B0466N12
			LON	w/WSE	96B0476N02	96B0476N12
			MPC	None	96B0466N03	96B0466N13
		ECM-CV	None	None	96B0467N01	96B0467N11
			None	w/WSE	96B0477N01	96B0477N11
			LON	None	96B0467N02	96B0467N12
			LON	w/WSE	96B0477N02	96B0477N12
			MPC	None	96B0467N03	96B0467N13
		ECM-CT	None	None	96B0468N01	96B0468N11
			LON	None	96B0468N02	96B0468N12
			MPC	None	96B0468N03	96B0468N13

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TC 006-012	Wiring Diagram TC 015-060
265/60/1	CXM	PSC	None	None	96B0450N10	96B0450N15
			None	w/WSE	96B0452N10	96B0452N15
			LON	None	96B0450N11	96B0450N16
			MPC	None	96B0450N12	96B0450N17
		ECM-CT	None	None	96B0454N01	96B0454N11
			LON	None	96B0454N02	96B0454N12
			MPC	None	96B0454N03	96B0454N13

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TC 006-012	Wiring Diagram TC 015-060
265/60/1	DXM2	PSC	None	None	96B0466N01	96B0466N11
			None	w/WSE	96B0476N01	96B0476N11
			LON	None	96B0466N02	96B0466N12
			LON	w/WSE	96B0476N02	96B0476N12
			MPC	None	96B0466N03	96B0466N13
		ECM-CV	None	None	96B0467N01	96B0467N11
			None	w/WSE	96B0477N01	96B0477N11
			LON	None	96B0467N02	96B0467N12
			LON	w/WSE	96B0477N02	96B0477N12
			MPC	None	96B0467N03	96B0467N13
		ECM-CT	None	None	96B0468N01	96B0468N11
			LON	None	96B0468N02	96B0468N12
			MPC	None	96B0468N03	96B0468N13

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TC 006-018	Wiring Diagram TC 024-060
208-230/60/3	CXM	PSC	None	None	N/A	96B0450N20
			LON	None	N/A	96B0450N21
			MPC	None	N/A	96B0450N22
		ECM-CT	None	None	N/A	96B0454N21
			LON	None	N/A	96B0454N22
			MPC	None	N/A	96B0454N23

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TC 006-018	Wiring Diagram TC 024-060
208-230/60/3	DXM2	PSC	None	None	N/A	96B0466N21
			LON	None	N/A	96B0466N22
			MPC	None	N/A	96B0466N23
		ECM-CV	None	None	N/A	96B0467N21
			LON	None	N/A	96B0467N22
			MPC	None	N/A	96B0467N23
		ECM-CT	None	None	N/A	96B0468N21
			LON	None	N/A	96B0468N22
			MPC	None	N/A	96B0468N23

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TC 006-018	Wiring Diagram TC 024-060
460/60/3	CXM	PSC	None	None	N/A	96B0450N30
			None	w/WSE	N/A	96B0452N30
			LON	None	N/A	96B0450N31
			MPC	None	N/A	96B0450N32
		ECM-CT	None	None	N/A	96B0454N31
			LON	None	N/A	96B0454N32
			MPC	None	N/A	96B0454N33

Electrical V-Hz-Ph	Control	Fan Motor	DDC	Options	Wiring Diagram TC 006-018	Wiring Diagram TC 024-060
460/60/3	DXM2	PSC	None	None	N/A	96B0466N31
			None	w/WSE	N/A	96B0476N31
			LON	None	N/A	96B0466N32
			LON	w/WSE	N/A	96B0476N32
			MPC	None	N/A	96B0466N33
			MPC	w/WSE	N/A	96B0476N33
		ECM-CV	None	None	N/A	96B0467N31
			None	w/WSE	N/A	96B0477N31
			LON	None	N/A	96B0467N32
			LON	w/WSE	N/A	96B0477N32
			MPC	None	N/A	96B0467N33
			MPC	w/WSE	N/A	96B0477N33
		ECM-CT	None	None	N/A	96B0468N31
			LON	None	N/A	96B0468N32
			MPC	None	N/A	96B0468N33
