TT Series
|
|
|
 |
 |
| |
Tranquility® Dedicated Outdoor Air Systems (TOV) Vertical Series
ClimateMaster Dedicated Outdoor Air Systems (TOV) Vertical ASeries provides the most complete solution for your water-source application. Our many options and configurations allow the design for outdoor air requirements to be incorporated into the water loop system, further enhancing the advantages of a WSHP application. The ability to precisely control leaving air dew point temperature in summer, handle extremely cold entering air temperatures in winter, and perform at part load conditions give designers unmatched flexibility in building design, Indoor Air Quality (IAQ) and energy efficiency.
Leaving Air Temperature Control
- Raised lance fins, rifled tubes maximize moisture removal
Evaporator Coil
- Supply air temperature controlled to ±0.2°F (±0.1°C)
- Substantial energy savings and ASHRAE 90.1 compliant
- Conditioned outdoor air can be introduced directly into space
Drain Pan
- Stainless steel pan minimizes corrosion
- Sloped design avoids hazardous puddling
Fans
- Forward curved centrifugal blowers or plenum fans
Refrigerant Reheat Coil
- Sized for neutral LAT (65 to 80°F, 18 to 27°C) with ±0.2°F (±0.1°C) control
- Adequate coil separation avoids re-hydration
Scroll Compressor
- State-of-the-art compressor technology for highest efficiency and reliability
- Quiet operation
- Units 8 tons (28kW) and larger, multiple compressors are staged to match the load
Electrical Service
- Single point connection, including heat – all units
Insulation
- Closed cell foam or polystyrene board in double-wall construction
- Superior to fiberglass insulation – eliminates fiber-release
into air
- Meets ASTM mold, mildew, moisture resistance specifications
Refrigeration Circuit
- Dissipates captured heat into water loop
- Unique design - no reversing valve
- Modulating hot gas reheat
Filters
- 4” deep extended surface, pre-filters (MERV 7)
Additional Options Increase Flexibility
- Optional coil coatings available for corrosive environments
- Single phase available on 4 and 5 ton (14 and 18 kW) units
- Optional power disconnects (fused and non-fused)
- Units available in 4 - 30 tons (14 to 105 kW)
- Contact factory for non-standard options
|
|
|
|
|
|
|
|
|
